Hi all, new member here so be kind!
I bought a no6 a number of years ago and have only recently put it all together to get it running. Two screws were broken off in the holes which have now been removed so I am in search of replacements. I am also missing another screw completely.
I have got some Whitworth screws coming but they will have allen heads to them so I am hoping one of you lovely people may have some spare screws you would be willing to sell to me?! I would love to replace the screws with matching ones if at all possible.
I have attached a photo, I am in need of another hex head the same to the one on the bottom row far left, another square head flange the same as the one next to the hex and two slot head the same as top row third from right and another shorter one.
I have measured them but not ever having measured screws and threads before I am not entirely confident!
The hex measures 3/16" diameter 3/4" long (excluding head) and has 48 TPI (I think!)
The square head is 3/16" diameter and 11/16" long (excluding head)
The longer cross head is 3/16" diameter x 1/2", shorter is 7/16" long and 5/32" diameter.
I know this is a tall order but you never know, no harm in asking
I look forward to hearing from you!
