Stitch holes

[rccolt45]

Hi guys,

My first post and I have a question. What do most of you use to puch holes for stiches in your rigs?

My tandy leather guy said I should pre-drill them with a drill press because a diamond awl will weaken the leather and the stich will pull thru eventually. I have tried and hate the llok of the drilled holes. So what do you guys use?

I was thinking abut using that 4 prong thing that Tandy sells ?? But will it go through two pieces of 7-8 oz leather?

Any advise would be helpfull

[tonyc1]

Hi guys,

My first post and I have a question. What do most of you use to puch holes for stiches in your rigs?

My tandy leather guy said I should pre-drill them with a drill press because a diamond awl will weaken the leather and the stich will pull thru eventually. I have tried and hate the llok of the drilled holes. So what do you guys use?

I was thinking abut using that 4 prong thing that Tandy sells ?? But will it go through two pieces of 7-8 oz leather?

Any advise would be helpfull

He hasn't done much handsewing then. An awl is the best and has been for quite a few hundred years!

Tony.

[rccolt45]

Well it was weird because he also said a diamond awl wouldn't go thru two pieces of 7-8 oz leather? Can this be right at all?

Also whats the difference between a diamond awl, a scratch awl and any other type of awl?

thanks for the replies.

[PeterD]

Hi guys,

My first post and I have a question. What do most of you use to puch holes for stiches in your rigs?

My tandy leather guy said I should pre-drill them with a drill press because a diamond awl will weaken the leather and the stich will pull thru eventually. I have tried and hate the llok of the drilled holes. So what do you guys use?

I was thinking abut using that 4 prong thing that Tandy sells ?? But will it go through two pieces of 7-8 oz leather?

Any advise would be helpfull

I use an awl. Used properly it doesn't weaken the leather. A drill removes leather an awl spreads the leather. It is also much faster if you learn the technique of manipulating the needles and awl at the same time. Always make your awl hole so the flat side of the hole is against the pulling side of the thread and don't pull the thread tight like your trying to garrot a sentry. Snug saddlestitching will stay tight, it doesn't require a come-along to keep it tight. I would suggest Al Stohlman's "Art of sewing leather" as a good overall reference.

Now having said that, there it a place for everything. I may drill holes if going through a really thick pieces of leather like a mug handle. I use an awl for most everything else unless it is something that is an odd sewing job like a soft quiver or tube were I use a lacing punch to prepunch everything.

[WaG35]

I use a 1/6th drill bit. It has worked good so far.

[Jordan]

1/16 maybe?

[Hilly]

Well it was weird because he also said a diamond awl wouldn't go thru two pieces of 7-8 oz leather? Can this be right at all?

Also whats the difference between a diamond awl, a scratch awl and any other type of awl?

thanks for the replies.

Welcome to the coolest place on the internet. The people here are fantastic! If you have a question about anything pertaining to leatherwork (or maybe not pertaining to leatherwork ) just ask, and you'll get a reply!

Yes, if your awl is good and sharp you will have no problems going through 2 layers of 8oz. leather. Get a C.S. Osborn awl with the diamond blade and when you get it, sharpen it. Just have to be a little careful to not put too much sideways pressure on them, as the blades are quite thin.

A diamond awl leaves a diamond shaped hole through your leather. A scratch awl is more for marking your leather by scratching lines instead of using a pen or pencil. It has a round blade with a pointy tip, sort of like a really thick needle. Not good for stitching. I also use my scratch awl for roughing up leather to give it some "tooth" before applying cement. They also make really neat holes in your foot if you're careless enough to drop them while wearing flip flops.

There's also a sewing awl sold by various places that hold a little spool of waxed thread inside, and makes (I belive) a lock stitch, somewhat like a sewing machine.

I second the recommendation on the book "The Art of Hand Sewing" by Al Stohlman. It will really help you out.

Oh yeah, that four prong "thing" will leave big holes in your leather, so unless you have big thread to fill those holes, I wouldn't do it (Don't ask me how I know).

Edited May 7, 2008 by Hilly

[Shorts]

+1 Hilly

I handstitch using the double stitch method. See Al Stohlman's book for technique. Cut and glue the pattern. Groove the stitch lines. Use a stitch wheel to mark the holes, then punch each hold with a diamond awl (I use 8/9oz leather and it works fine). I use glover's needles to stitch as the eye is small and does not deform and break like the stitchers needles. Be aware, glover's needles are sharp so slicing thread may happen more. Technique is vital...and dull blades :D

If you want easy, I still use the beginner's kit from Tandy. It includes Stohlman's book, the 4 tools (awl, groovers, wheel and scratch awl) and thread. (I can't recall exactly so please refer to the website). Now, I've added individual things here and there but this is a great way to get the tools and info you need to get started.

Good luck and welcome

Edited May 7, 2008 by Shorts

[TwinOaks]

An awl is the way to go, and definitely you need to sharpen it. When using a drill bit, which I've done, you have to match the bit to the thread, otherwise you'll get gaping holes when the stitch is complete. It looks awful. An awl makes a nice, neat little hole that closes up around the thread. Do be sure to keep your fingers out of the way when pushing the awl through. They are quite a bit softer than leather and offer little resistance to the awl tip.

[Srigs]

When I need to do some hand work, I use a 1, 3 or 4 rectangle punch that makes it easy compared to diamond shape and don't like drilled at all. It is also very hard to cut your hand open unlike an awl
