Uwe Posted September 23, 2015 Report Posted September 23, 2015 Congratulations! You'll have five or six sewing machines like the rest of us before too long - it's an addiction that has not yet been recognized by the WHO. Quote Uwe (pronounced "OOH-vuh" ) Links: Videos
Members CaroCaro Posted September 24, 2015 Author Members Report Posted September 24, 2015 Yeah, great isnt it. At that low cost I could not resist. Now I need to clean the old lady up. I am sure leatherworker.net has some information on that. Quote
Members shoepatcher Posted September 24, 2015 Members Report Posted September 24, 2015 CaroCaro, Your machine is a 335-17B H2L That means it was originally a binding machine (subclass 17) It is a B class as to ability to sew items. C is a heavier class than B, D is the heaviest machine in that class. These letters usually mean the hole in the feed dog would be smaller and the balance wheel may or may not be smaller. The H2 is the lift. H3 being 11mm, H4 is the High lift at 14 mm clearance under the presser foot. Not sure what the lift is on the H2 machines, L means for leather. No P so there is no 4- motion drop feed on the feed dog, it just goes back and forth. I have the instruction manual and the parts manual for the machine but it is not on a PDF file, only hard copy. glenn Quote
Uwe Posted September 24, 2015 Report Posted September 24, 2015 Great info Glenn, thanks! Any chance I can borrow your hardcopy manual to scan it into a PDF file and make it available to others? Quote Uwe (pronounced "OOH-vuh" ) Links: Videos
Members Sonydaze Posted September 25, 2015 Members Report Posted September 25, 2015 I have slightly earlier PDFs of the instruction, service and parts manuals. The service manual was published June, 09. Email me: gord(at)bound2please.com if you would like a copy. Quote http://www.bound2please.com Sewing machines: 3 - Sunstar 590BL, Artisan Toro 3200, Juki LK-1900HS, Juki DDL-8500-7, Juki DDL-5550N, Pfaff 138-6/21, Pfaff 546-H3, Pfaff 335-H3, Adler 221-76, Singer 144WVS33, Singer 29K-51, Siruba 747B
Uwe Posted September 25, 2015 Report Posted September 25, 2015 Thanks for offering Sonydaze. I have a feeling your '09 manuals are for the new casting white Pfaff 335 models. The manuals that apparently have no online presence at all are for the old casting of the Pfaff 335, about 30 or more years old. I'd like to find hard copies of vintage owner/parts/service manuals from the '80s or earlier for the Pfaff 335 and put them online as PDFs. Quote Uwe (pronounced "OOH-vuh" ) Links: Videos
Members Sonydaze Posted September 25, 2015 Members Report Posted September 25, 2015 No problem Uwe, I picked up a 335-H3 (not white, but has Quick Digital) several years ago. These were the closest manuals that I could find at the time. Quote http://www.bound2please.com Sewing machines: 3 - Sunstar 590BL, Artisan Toro 3200, Juki LK-1900HS, Juki DDL-8500-7, Juki DDL-5550N, Pfaff 138-6/21, Pfaff 546-H3, Pfaff 335-H3, Adler 221-76, Singer 144WVS33, Singer 29K-51, Siruba 747B
Hockeymender Posted September 25, 2015 Report Posted September 25, 2015 Uwe, I should have the same manuals as Glenn, I will look to be sure. PM me and I'm sure we can work something out to get them uploaded. Quote Regards, Joe Esposito www.hockeymenders.com instragram: @hockeymenders.com
Members jimi Posted September 27, 2015 Members Report Posted September 27, 2015 Hi There, i have an old 335 from the 1950´s. if you find any old material on these machines would it be possible to get a copy, thanks,jimi. http://leatherworker.net/forum/index.php?showtopic=55790&hl=%2Bpfaff+%2B335+%2Bjourney+%2Bthe+%2Bunknown Quote
Ambassador leatheroo Posted September 27, 2015 Ambassador Report Posted September 27, 2015 pfaff335 parts.pdfpfaff adjustment.pdfhey all, i have an older 335 and i find these documents relevant to my machine...cheers Quote "]http://leatheroo.blogspot
