You have to find a couple of pieces of angle iron to put under the to support the left end of the machine when you mount a long arm on a shortarm stand.The legs will stick out approx 4" if I remember correctly.
Yes,I seen clutchmotors on these machines.
I hope you have some paint left for the new bobbinwinder......it's gray & you might have to move your handwheel alittle to the right for it to work.
Bob
Yes,it should handle the belts ok,just be sure to hold on to the needle thread the first 3 stitches as this machine doesn't have a safety clutch & you take a chance of knocking it out of time.
Bob
We used to sell them years ago & people would break gears in them just trying to sew with #138 thread as a matter of fact it really didn't matter what size thread just sewing with the machine caused them to break.The gears are almost impossible to find.
Get Juki , Nakajima or Consew if you want to avoid problems.
Bob
Chris,
I had a customer come in around 3:30 & guess what she bought a 406 so I finished up with her around 4:30 & tried you again right before I left & got your voicemail
so I didn't leave a message,I'll be in tomorrow from 8-12 est
Bob
Chris,
No,the only difference other than the name is on the Consew there's a button you need to push on when you change the stitch length that the Chandler doen't have.So we sell more Chandlers than Consews do to the price difference of $200.00
Bob
Yes,the 206 has a large bobbin,on the 226 when you change the bobbin sometimes you have to take the material out of the machine to be able to get to the bobbin & then after you change the bobbin you have to pull the thread up through the needle plate,on the 206 you just leave a tail of thread about an inch long put the bobbin back in & start sewing again.
Bob
The 226 has a vertical hook were the bobbin goes in to the right of the needle,the 206 has a horizontal hook & the bobbin goes in from underneath & you take the bobbin case out on the 206 when you change it also the 206 can use #207 thread.
Bob
You should be able to use a #207 w/a #23 needle,what model 145 is it?the H4 high lift uses a longer needle than the H3.We do have needles,parts & etc for it as we are a Pfaff Dealer.
Bob
My guess is the inside foot parts are worn allowing the inside foot to move left & right as your sewing.Turn the machine around by hand & see if it moves left to right.
Bob
Carol,
The 7-9 was replaced by model# 7-34 you mighjt find more info under that #,years ago we used to modify these to sew to 3/4" of leather as they come from the factory they will sew 1/2" they were made for general heavy sewing like tarps & etc & can use a real large thread.
We still have some parts & needles in stock.
Bob
This is a model 30,very commonly used for shoe repair & we sell alot of them for sewing on patches on biker jackets,the foot swivels & sews in any direction.The problem is if your sewing on a finished good that you want to look nice on top you'll find that the teeth that pull the leather will dig in & leave marks.
Let me know the model# on the little brass plate on the front as it's either a 30-1 or a 30-7
Bob
Scott,
Trox is correct in saying you can use the newer manual,your machine might adjust different but it still needs to look like the last page of the manual,it shows the shuttle driver & needle relationship.
Bob
That pin is a taper pin that you hammer out from the back ,you might want to put a small round pipe in front w/a hammer behind it then hit from the back.
Bob
It's to bad your having a problem as that should be a good machine for you as long as you thread it & put the needle in correctly.We always try to get the customer to test the machine before it leaves & the we can also watch them thread it to make sure it sewing to their satisfaction,you should take it back & tell them it isn't sewing like it should & maybe it just needs some minor adjustment.
Bob
